High-precision rolled strips for welded tubes

Welded tubes made of high-precision strips are used in various industries such as the medical industry, the aerospace industry or in measurement and control technology.

For the production of welded and drawn tubes, Lamineries MATTHEY supplies rolled and cut strips in the thicknesses and widths specified by our customers. Welding can be done by laser or other technologies.

The technical requirements for these strips are often the same: precision rolled strips, delivered in a soft condition and cut to very specific widths and with very tight tolerances according to customer requirements. The thickness can vary greatly, but is typically between 1.00 mm and 0.05 mm.

In the medical field, these strips can be used to make capillary tubes for applications such as needles, stents and surgical instruments.

Lamineries MATTHEY supplies the aerospace industry with strips to produce special alloy tubes with a round cross-section or in the form of profile tubes e.g. for heat exchangers, temperature probes, linear displacement sensors, Pitot tubes.

In measurement and control technology, thin-walled tubes with small diameters that adhere to strict tolerances in terms of dimensions and mechanical properties are used, for example in measuring and control devices as well as in temperature sensors.

We supply the market with many different alloys required for these welded pipe applications. Here are the main examples:

Stainless steels
1.4301 – Stainless steel / X5CrNi18-10 / ~ AISI 304
1.4306 – Stainless steel / X2CrNi19-11 / AISI 304L
1.4404 – Stainless steel / X2CrNiMo17-12-2 / ~ AISI 316L / ~ AISI 316 / 1.4401
1.4401 – Stainless steel / X5CrNiMo17-12-2 / ~ AISI 316
1.4441 – Stainless steel (implants) / X2CrNiMo18-15-3 / ISO 5832-1 / ASTM F139

Cobalt-chromium alloys
Phynox® / Elgiloy – cobalt superalloy R30003 / R30008 / ASTM F1058/ISO 5832-7
MP35N® – R30035 / ASTM F562 / ISO 5832-6
Duratherm® 600 / 2.4781
L-605 – R30605

Nickel alloys
NiCr15Fe – (Inconel) alloy 600 / ~ 2.4816 / N06600
NiCr22Mo9Fe5 – (Inconel) alloy 625 / ~2.4856 / N06625
NiCu30Fe – (Monel) alloy 400 / 2.4360 / N04400
Alloy 718 (Inconel, Hastelloy) / N07718 / 2.4668

Why consult Lamineries MATTHEY?
Our stock range of special alloys for these applications is very extensive and allows us to offer attractive production times.

We have great flexibility in production tooling, allowing us to produce specialty products even in small quantities and to shear the specific widths required for these applications with tight tolerances.

We also do contract work for you such as rolling, heat treatment, straightening, shearing, etc.
